Howo - A7

Senin, 16 November 2015

HOWO-A7 heavy duty truk , seni yang luar biasa di bidang otomotif domestik, penuh ekspresi dari konsep truk berat. Desain halus, teknologi sangat baik, yang akan mempesona Anda sebagai karya yang inovatif.

Kenyamanan, keamanan, keandalan, dan intellectualization ke tingkat internasional. Rendah konsumsi bahan bakar — pilihan paling ekonomis.

Truk HOWO-A7 didesain oleh insinyur Italia terkenal, gaya klasik Eropa diadopsi dan juga menunjukkan tren pengembangan internasional.

HOWO-A7 berisi semua jenis kendaraan, termasuk traktor, truk, tipper, mixer beton dan tujuan khusus kendaraan lain.

Drive jenis: 4 × 2, 6 × 2, 6 × 4, 8 × 4, dll.

Mesin listrik rentang: 270PS-460PS.

Engine	Maker: Steyr
	Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling,turbo-charging & intercooling
	Engine model: WD615.47/ WD615.69
	Max. output: 371hp@2200rpm/ 336hp@2200rpm
	Max torque: 1500NM@1100-1600rpm / 1350NM@1100-1600rpm
	Bore/Stroke(mm):126/130
	Mean Position Speed: 9.53m/s
	Compression ratio:15.5:1
	Specific fuel consumption: 198g/Kwh
	Displacement: 9.726 liters
Clutch	Φ430 diaphragm clutch
Transmission	SINOTRUK HW9
Front Axle	HOWO08 front axle
Rear Axle	HC16 ( double reduction driving axle)
Chassis	Front overhang (mm): 1500
	Rear overhang (mm): 1870
	Wheel base (mm): 3425+1350
	Rear track (mm): 1830/1830
Steering	ZF8098 integral type power-steering
Wheel & Types	12.00R20 Radial tire
Wheel & Types	Spring: 10/12
Driver's cab	A7 , flat head, double doors, tippable, normal-roof with A/C
Dimensions in (mm)	Dimension(mm): 854524963170
	Max speed: 75km/h
	Max. gradeability(%): 25
	Approach angle: 19degree
	Departure angle:23 degree
	5th wheel: 3.5"
weight	Kerb. mass: 12460kg
	Total mass: 25000kg
	Fuel tank capacity (L): 400L Aluminium alloy
	Fuel consumption (L/100km): 36
BODY	Inner size: 5800x2300x1500
	Capacity: 20.01CBM
	Thickness of steel(mm): bottom 8, side 4
	Tipping system: Middle tipping F type
